specification
| LED type | 2835SMD LED |
| Beam Angle | 165° |
| Luminous Flux(lm) | 142lm |
| LED Qty | 1 pcs |
| Working voltage | DC12V |
| power（W） | 1.5W |
| Dimension | 44*28*8.8mm |
| Available Color | W/WW/CW |
| Certification | CE&ROHS&UL |
| Working Temperature | -40---+60°C |
| Store Temperature | -40---+70°C |
| IP Degree | IP65 |
| Maximum length in serial connection | 20pcs |
Package
Every 20 pcs per a string,100pcs/bag ,1200pcs per a carton box.
Carton size:530*375*275mm
Gross Weight: 14.3KG/a caron box
Features
1.High effciency SMD 2835 LED
2. 165 degree beam angle
3.Constant current driver ensuring a string of module working stably
4.Aluminum PCB with excellent heat dissipation
5. 5 years warranty
6.Suitable for 3-8" back-lighting lightbox
