specification
| LED type | 2835SMD LED |
| Beam Angle | 45° |
| Luminous Flux(lm) | 135lm |
| LED Qty | 3 pcs |
| Working voltage | DC12V |
| Driving modle | Constat current |
| Power(W) | 1.5W |
| Dimension | 44*28*14.5mm |
| Available Color | W/NW/CW |
| Certification | CE&ROHS&UL |
| Working Temperature | -40---+60°C |
| Store Temperature | -40---+70°C |
| IP Grade | IP65 |
| Maximum length in serial connection | 20pcs |
Package
Every 20 pcs per a string,100pcs/bag ,1200pcs per a carton box.
Carton size:53*38*28
Gross Weight: 16.6KG/a caron box
Features
1.High effciency SMD 2835 LED
2. 45*15 degree beam angle
3.Constant current driver ensuring a string of module working stably
4.Aluminum PCB with excellent heat dissipation
5.DC12V low voltage input, reliable and safe.
6. 5 years warranty
7.Suitable for 6-32cM side-lighting lightbox
